TITAN Core is the fastest way to add HD haptics to your product.
Arduino
Compatible
Features
TITAN Core is perfect for prototyping haptics, and can also be used for testing motors, effects, games and other haptic applications. It is a fully contained Haptics Evaluation Board with a 32-bit ESP32 Processor, Wi-Fi, Bluetooth, Haptics, DAC, DSP, and in a tiny, low-cost footprint.
- Wi-Fi, Bluetooth, haptics, DAC, DSP
- Drive up to 3 discrete haptic motors
- Tiny 32-Bit ESP32 processor
- Integrated Power Management
- MP compatible
- FCC certified
- Dual-channel Class D Audio Amplifier
Break-off USB and power circuitry
Pinout
Top
Bottom
Tech Specs
Mechanical
Dimensions
44.8 x 20.8 x 18.6 mm
Features
- Dual-channel Class D Audio Amplifier
- 3 haptic channels with convenient screw-in headers
- Bluetooth, USB and WiFi Connectivity
- Break-off USB and power circuitry
- Integrated Power Management
Hardware
Processor:
ESP32
Pins:
Serial TX/RX
LED and PWM Motor Control (6)
I2C, I2S
SPI
ADC
VBUS & 3.3VREF
Power method:
USB Bus Power & Battery Charging
Operating voltage:
3.3V or 5V Input/Output
Up to 11V Out*
*contact TITAN for voltage applications above 5V
Certifications:
FCC
Get TITAN Core for your next project
Applications
Gaming, AR/VR
Automotive
Wearables
Headphones
Touchscreens
Wellness
The TITAN Core comes preloaded with Vector Haptics firmware, with three selectable modes:
- Preprogrammed Haptic pattern loop
- Real-time USB serial haptic playback (with Vector Haptics primitives)
- Bluetooth Audio-to-haptics
Developer Program
Bring the magic of advanced haptics to your next project.
Get access to downloads, developer kits, datasheets, engineering support, reference designs, and more.
